BX-SCREED

Binder for Screeds for Floor Levelling

BINDER FOR SCREEDS

BX SCREED

BX Screed is a binder for screeds, used for floor levelling before fixing tiles and natural stones with the wet-on-wet technique. It can also be used as a dry screed for underlay application and floor levelling.

BX - SCREED
BINDER FOR SCREEDS
DISCRIPTION

Binder for Screeds for Floor Levelling Before Fixing Tiles and Natural Stones

FEATURES AND ADVANTAGES
  • Prolonged workability
  • Does not create stains on stones
  • No efflorescence effect
  • Rapid-drying and no curing
  • Very low shrinkage

AREAS OF USE

Areas Of Use
Surfaces Uses Materials
Concrete Floors Internal - External Screeds All Type Of Tiles And Sizes
Low-Density Concrete Domestic Applications Low Thickness Slabs
Heat-insulating And Soundproofing Panels Commercial Applications Recomposed Materials
Existing PCC And IPS Industrial Applications Glass And Ceramics Mosaics

TECHNICAL DATA COMPLIANT

Pack 40 kg bags
Shelf life 12 months in the original packaging Protect from humidity
Apparent volumetric mass 1.2 kg/dm³
Screed thickness 20-80 mm
Coverage per cm of thickness Depending on dosage and thickness
Temperature of use +5℃ to +35℃
Pot life +23℃ ≈ 3 hrs
Foot traffic +23℃: Dry screed ≈ 24 hrs
Waiting time for fixing (+23℃) Tiles ≥ 24 hrs
Hardwood floors ≥ 5 days

Performance

Recommended Dosages (for fixing all types of vitrified tiles and natural stones)
Floor Use Mix Ratio (Volume) Consumption (per m² per cm thickness) Water Compressive Strength 28 Days
For Small Tile 1:6 1.70 kg 40% by the weight of BX Screed 22 MPa
For Stone / Large Tile Fixing 1:5 2.10 kg 40% by the weight of BX Screed 24 MPa
For Heavy Traffic 1:4 2.50 kg 40% by the weight of BX Screed 26 MPa
* Depending on the humidity of the inert material. Local standards might request different proportions.

HOW TO USE

  • Preparation of the surface: all surfaces must be dimensionally stable according to IS 1443-1972, level, cured, undamaged, compact, rigid, resistant, dry and free from any debonding agents and from rising damp.
  • Screed preparation: mix BX Screed with water and sand until a semi-dry consistency is obtained. The sand must be cleaned from dust and earth residues. This makes screeds 20 to 80 mm thick. The amount of mixing water varies with the humidity of the inert material.
  • Application: apply BX Screed with the traditional methods for cement-based screeds. Prepare the levelling layers, cast and compact the mix, flatten it, and give a final smoothing with a power floater or mechanical means. Compact the screed carefully to get the required mechanical performance.
  • Cleaning: wash residual traces of BX Screed off tools and machinery with water before the product hardens.

GENERAL NOTICES

  • Abide by any standards and national regulations.
  • Use the recommended dosages.
  • Do not add other binders, additives or water to the mixture during the setting phase.
  • Low temperatures and high relative humidity lengthen the drying time of the screed.
  • Too much water, or inert materials with a grading lower than recommended or not assorted, will reduce strength and drying time.
  • Before fixing hardwood floors and resilient materials, check residual moisture with a calcium carbide hygrometer.
  • Do not moisten the screed, and protect it from direct sunlight and air currents for the first 24 hours.
